Airmar CM599LH 1-3kW Pocket Mounted Transducer - No Connector - CM599C-LH 31.4 lb

Airmar CM599LH 1-3kW Pocket Mounted Transducer - No Connector - CM599C-LH

CM599LH 1-3kW Pocket Mounted Transducer - No Connector Having the right tool for the job makes the job easier and gives better results. The right tool for covering deep-water haunts of swordfish, tuna, and other species is a 2 to 3 kW, low and high-frequency transducer. The Chirp-ready CM599LH gives the deep-water performance of the low frequency down to 3000 m (10000') plus the incredible resolution that the high-frequency band delivers. The CM599LH is packed with a twenty-four-element, low-frequency array that operates at anywhere between 28 and 60 kHz. The single, high-frequency ceramic operates at any frequency between 130 and 210 kHz and has a narrow, 8° to 4°, beamwidth. Features: Depth and fast-response water-temperature sensing 2 to 3 kW of power for exceptional deep-water performance Low frequency: 28 to 60 kHz 23° to 9° port-starboard beamwidth 11° to 5° fore-aft beamwidth Maximum depth to 3048 m (10000') High frequency: 130 to 210 kHz 8° to 4° beamwidth Maximum depth to 457 m (1500') 112 kHz of total bandwidth from one transducer Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth Resin housing with curved-edge design for wet-box installation Can be installed in a cavity or welded tank Also available as thru-hull external (R509LH) and in-hull (R599LH) mounts Patented Xducer ID® technology Specifications: Frequency Band: Low-High Functions: Depth, Temperature Material: Urethane Mounting Style: Tank, Cavity, Pocket/Keel Mount Connector: Bare Wire Display Connector: 0 Hull Material: Fiberglass or metal Max Vessel LOA: 8 m (25') and above High Frequency: 130-210 kHz Common Use: Fishing, Commercial Fishing Max Deadrise Angle: Any Tilted Element: No Low Frequency Beamwidth: 11°x23°-5°x9° Low Frequency: 28-60 kHz High Frequency Beamwidth: 8°-4° Max Deadrise: Accommodates any deadrise angle based on custom installation Power Rating: 2-3 kW Single or Dual Frequency: CHIRP-Ready Dual-Band Country of Origin: USA Cable-Length: 15 m (49') Weight: 14.2 kg (31.2 lb.) Max Depth: Low frequency- 3048 m (10000'), High frequency- 457 m (1500') This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications

Product Resources

• Quick Guide Literature (pdf) Url
• Brochure Literature (pdf) Url
• Installation Guide (pdf) Url
